The CUI Inc. PYBE30-Q48-S12-U is an enclosed DC-DC converter designed for ITE (Commercial) applications. It features a 4:1 input voltage range of 18-75 Vdc and provides a single regulated output of 12 Vdc at up to 2.5A, delivering a maximum power of 30W.
Key electrical specifications include 1500 Vdc isolation and an efficiency of up to 88%. The converter is designed to operate within a wide temperature range of -40°C to +80°C. It meets the EN/BS EN 62368-1 standard and is CE approved.
This chassis mount converter has dimensions of 55.0mm x 52.3mm x 19.0mm. It includes continuous short circuit protection and a remote on/off control feature. The PYBE30 series offers industry-standard pin-outs for ease of integration.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is from 18 VDC to 75 VDC.
The output voltage is 12 VDC.
The maximum output current is 2.5 A.
The typical efficiency is 88%.
It complies with EN/BS EN 62368-1 standards.
It operates from -40°C to 80°C with derating.
It is chassis mount.
