| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
856 pcs
|
856 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Plating | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Housing Color | |
| Ingress Protection | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Orientation | |
| Primary Material | |
| Shell Material | |
| Shielding | |
| Type |
The PX0410/04P/5055 is a 4-position circular plug housing from the Buccaneer 400 series by Bulgin Components, designed for power applications requiring robust environmental sealing. It accepts male pins and is configured for free-hanging (in-line) mounting with a threaded coupling ring for secure mating.
This housing is constructed from polyamide (PA) and nylon with a UL94 V-0 flammability rating, and includes a backshell and coupling nut. It offers IP68 and IP69K protection, making it suitable for submersion and high-pressure washdown environments. The keyed orientation ensures proper alignment during connection.
Electrical ratings for the 4-contact configuration are 5A per contact at 125V. The contacts (sold separately) are crimp or solder cup type with gold plating. The housing accepts cables with diameters from 3 to 7 mm and has a 2.5 mm contact engagement length for reliable electrical integrity.
With UV-resistant material and a robust design, this connector is ideal for industrial, marine, and outdoor applications where durability and moisture resistance are critical.
| Qty | Low | High |
|---|---|---|
| 1+ | $13.64 | $13.64 |
| 10+ | $12.91 | $12.91 |
| 25+ | $12.10 | $12.10 |
| 60+ | $11.52 | $11.52 |
| 120+ | $10.96 | $10.96 |
| 300+ | $10.28 | $10.28 |
| 540+ | $9.79 | $9.79 |
| 1,020+ | $9.32 | $9.32 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 4 positions (power).
5 A per contact.
125 V.
Free hanging (in-line).
IP68 and IP69K.
Polyamide (PA) and nylon, with UL94 V-0 flammability rating.
Yes, UV resistant.
