The Astrodyne TDI PWC12-12S is a micro-miniature 12 Watt switching power supply designed for ITE (Commercial) and Medical applications. This open frame AC/DC converter provides a single 12VDC output at 1A, delivering a total of 12W of power.
It operates with a universal input voltage range of 90-264 VAC at 47-440 Hz, offering flexibility for global use. Key electrical specifications include a typical efficiency of 80%, load regulation of ±1% max, and line regulation of ±0.5% max. The unit provides 3,000 VAC input to output isolation and meets EN55022 Class B EMI standards.
Packaged in a 6-SIP module with through-hole mounting, the PWC12-12S has dimensions of 2.00" L x 0.69" W x 1.12" H (50.8mm x 17.5mm x 28.5mm). It is rated for an ambient operating temperature range of -25°C to +65°C. Safety certifications include CE, cURus, and UL, with compliance to IEC 62368-1 and IEC 60950-1 standards.
The PWC12-12S provides a nominal output of 12 VDC at 1 A, for a total power of 12 W.
The input voltage range is 90 to 264 VAC at 47-440 Hz.
The operating ambient temperature range is -25°C to +65°C.
The PWC12-12S is housed in a 6-pin SIP (Single In-line Package) module with through-hole mounting.
The typical efficiency is 80%.
The converter complies with IEC 62368-1 and IEC 60950-1 safety standards.
