The Astrodyne TDI PWC-15S is an open frame AC/DC converter designed for ITE (Commercial) and Medical applications. It operates with a universal input voltage range of 90 to 264 VAC and provides a single output of 15V at 330mA, delivering a total of 5W of power.
This converter features an efficiency of 75% and includes universal input functionality. Its dimensions are 49.0mm in length, 13.0mm in width, and 28.5mm in height. The operating temperature range is from -25°C to 65°C with derating.
Designed for reliable integration, the PWC-15S utilizes through-hole mounting and comes in a 6-SIP module package. It holds approvals from CE, cURus, and UL, and complies with standard numbers 60601-1 and 60950-1, making it suitable for various commercial and medical device designs.
90 to 264 VAC (universal input).
6-SIP Module with through-hole mounting.
-25°C to 65°C with derating.
15 VDC.
330 mA.
5 W.
CE, cURus, UL. Complies with standards 60601-1 and 60950-1.
