PVT422SPBF The Infineon Technologies PVT422SPBF is a Solid State Relay with a SPST-NO (1 Form A) x 2 circuit. It operates with a load voltage range of 0-400V and a load current of 120mA.
Mfr Part #:

PVT422SPBF

Available from 1 distributors
Mfr Name: IOR
IOR
The Infineon Technologies PVT422SPBF is a Solid State Relay with a SPST-NO (1 Form A) x 2 circuit. It operates with a load voltage range of 0-400V and a load current of 120mA.
✓ Total Stock: 50 pcs
$ Price Range: $0.99

PVT422SPBF Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
50 pcs
On Request
50 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PVT422SPBF Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Circuit
Failure Rate
Load Current
Mounting Type
Output Type
Supplier Device Package
Termination Style
View Similar Products (0)

PVT422SPBF Description

Short technical summary and product information.

The Infineon Technologies PVT422SPBF is a Solid State Relay designed for various applications. It features a SPST-NO (1 Form A) x 2 circuit configuration, allowing for versatile switching capabilities.



This relay supports an output voltage range of 0 V to 400 V and can handle a load current of up to 120 mA. The input voltage required to activate the relay is 1.2 VDC. The on-state resistance is a maximum of 35 Ohms.



Packaged in an 8-SMD (0.300", 7.62mm) case, the PVT422SPBF is designed for surface mounting with gull wing termination style. It belongs to the PVT, HEXFET® series and is currently in an active product status.



This component is suitable for applications requiring reliable solid-state switching within its specified electrical and environmental parameters.

PVT422SPBF Quick Information

Product Type: Solid State Relay
Series: PVT, HEXFET®
Canonical Name: Infineon Technologies PVT422SPBF Solid State Relay

PVT422SPBF Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PVT422SPBF Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

PVT422SPBF Features

  • SPST-NO (1 Form A) x 2 circuit configuration.
  • Supports 0 V to 400 V load voltage.
  • Handles up to 120 mA load current.
  • Requires 1.2 VDC input voltage.
  • Surface mountable 8-SMD package.

PVT422SPBF Applications

  • Used in electrical switching circuits
  • Suitable for AC and DC load control
  • Ideal for compact circuit designs
  • Applicable in automation and control systems

PVT422SPBF FAQs

6 frequently asked questions generated from this part’s specifications.
What is the load voltage range for the PVT422SPBF?

The load voltage range for the PVT422SPBF is 0 V to 400 V.

What is the maximum load current for the PVT422SPBF?

The maximum load current for the PVT422SPBF is 120 mA.

What is the input voltage required for the PVT422SPBF?

The input voltage required for the PVT422SPBF is 1.2 VDC.

What is the on-state resistance of the PVT422SPBF?

The maximum on-state resistance of the PVT422SPBF is 35 Ohms.

What type of circuit does the PVT422SPBF feature?

The PVT422SPBF features a SPST-NO (1 Form A) x 2 circuit.

How is the PVT422SPBF mounted?

The PVT422SPBF is designed for surface mounting.
