PV36Y502C01B00 The Bourns PV36Y502C01B00 is a 5kΩ trimmer potentiometer with a 0.5W power rating. It features a Cermet resistive material and PC pin termination.
Mfr Part #:

PV36Y502C01B00

Available from 1 distributors
Mfr Name: Bourns
Bourns
The Bourns PV36Y502C01B00 is a 5kΩ trimmer potentiometer with a 0.5W power rating. It features a Cermet resistive material and PC pin termination.
✓ Total Stock: 1,436 pcs
$ Price Range: $0.05

PV36Y502C01B00 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Tomark Electronics Ltd ✓
Non-Authorised Inventory information
1,436 pcs
On Request
1436 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PV36Y502C01B00 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Adjustment Type
Lead Style
Mounting Type
Number of Turns
Power (Watts)
Resistance
Resistive Material
Tape & Reel
Temperature Coefficient
Termination Style
Tolerance
View Similar Products (0)

PV36Y502C01B00 Description

Short technical summary and product information.

This Bourns PV36Y502C01B00 is a multiturn trimming potentiometer from the PV36 series. It offers a resistance value of 5 kΩ with a tolerance of ±10% and a power rating of 0.5W at 70°C. The resistive material is Cermet, known for its stability and reliability.



The potentiometer is designed for through-hole mounting and features PC pin termination. It has 25 turns for precise adjustment and a top adjustment type. The sealed design and standoffs allow for thorough PC board washing.



Environmental testing includes temperature cycle, humidity, vibration, and shock resistance, with specified changes in total resistance (DTR) and voltage setting stability (V.S.S.). The RoHS 3 compliant status indicates adherence to current environmental regulations.

PV36Y502C01B00 Quick Information

Product Type: Trimmer Potentiometer
Series: PV36
Canonical Name: Bourns PV36Y502C01B00 Multiturn Trimming Potentiometer
Subcategory: Trimming Potentiometer

PV36Y502C01B00 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PV36Y502C01B00 Estimated Pricing

Qty Low High
1+ $0.05 $0.05

Estimated market price range - modelled values for guidance only, not live distributor offers.

PV36Y502C01B00 Features

  • 5kΩ resistance with ±10% tolerance.
  • 0.5W power rating at 70°C.
  • Cermet resistive material for stability.
  • 25 turns for precise adjustment.
  • Through hole mounting with PC pins.

PV36Y502C01B00 Applications

  • Ideal for circuit calibration adjustments.
  • Suitable for applications requiring fine tuning.
  • Used in electronic test equipment.
  • Applicable in control systems.

PV36Y502C01B00 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the resistance value of the PV36Y502C01B00?

The resistance value is 5 kΩ.

What is the power rating of this trimmer potentiometer?

The power rating is 0.5W, or 1/2W.

What is the tolerance for the PV36Y502C01B00?

The tolerance is ±10%.

What is the temperature coefficient?

The temperature coefficient is ±100ppm/°C.

What type of material is used for the resistive element?

The resistive material is Cermet.

How many turns does this potentiometer have?

It has 25 turns.

What are the environmental specifications for temperature cycle?

The change in total resistance (DTR) is ±2% after temperature cycling.
