The PV150-29B24 from Morning Star Industrial is a 150W enclosed DC DC converter designed for demanding applications. It operates with an ultra-wide input voltage range of 250 to 1500VDC, making it suitable for renewable energy systems and industrial control.
This converter provides a stable 24V output at 6.25A, with a high efficiency of 87%. It offers robust isolation of 4000VAC between input and output, ensuring safety and reliability. The operating temperature range is -40°C to +70°C with derating.
Designed for chassis mounting, the PV150-29B24 has a compact size of 168.0mm x 111.2mm x 42.5mm. It includes protection features such as input undervoltage protection within the 215-235 VDC range, contributing to stable operation under abnormal conditions.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 250-1500 VDC.
The output power is 150W.
The output voltage is 24V.
The efficiency is 87%.
The isolation voltage is 4000 VAC.
The dimensions are 168mm in length, 111.2mm in width, and 42.5mm in height.
-40°C to 70°C with derating.
