| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
173 pcs
|
173 pcs | On Request | 1 | On Request | On Request | 0549+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Auto-Track Sequencing | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| On/Off Inhibit | |
| Operating Temperature | |
| Output Overcurrent Protection | |
| Output Voltage | |
| Output Voltage Sense | |
| Overtemperature Protection | |
| Prebias Start-Up | |
| Safety Agency Approvals | |
| Shipping/Carrier | |
| Standard Package Quantity | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The Texas Instruments PTV12020WAH is a non-isolated DC DC switching regulator module designed for powering complex digital systems. It operates from a 12V input and provides a step-down conversion to a wide range of output voltages, adjustable from 1.2V to 5.5V, with a maximum output current of 16A.
Key features include high efficiency up to 93%, on/off inhibit, prebias start-up, undervoltage lockout, and auto-track sequencing. For load regulation, an output voltage sense is provided. Protection features include nonlatching overcurrent protection with auto-reset and overtemperature shutdown.
This module is housed in a 12-pin SIP package, minimizing board space. It is suitable for applications such as multivoltage digital systems, high-end computing, and networking. The operating temperature range is -40°C to 85°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $19.86 | $19.86 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The PTV12020WAH offers up to 16-A output current.
The PTV12020WAH operates from a 12-V input voltage.
The output voltage of the PTV12020WAH can be adjusted from 1.2 V to 5.5 V.
The PTV12020WAH operates within a temperature range of -40°C to 85°C.
The PTV12020WAH is supplied in a 12-pin SIP Module package.
Yes, the PTV12020WAH features nonlatching overcurrent protection with auto-reset.
Key features include Auto-Track sequencing, on/off inhibit, prebias start up, undervoltage lockout, and overtemperature protection.
