| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,568 pcs
|
2568 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage Range | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The Texas Instruments PTV05020WAH is a high-efficiency Non-Isolated Point-of-Load (PoL) DC-DC converter module. It operates from a 4.5V input and provides a regulated output voltage adjustable from 0.8V to 3.6V, capable of delivering up to 18A of output current. The module achieves up to 94% efficiency, making it suitable for powering low-voltage, high-current digital loads such as FPGAs, ASICs, and processors in ITE (Commercial) applications.
This through-hole module is housed in a compact 12-SIP package measuring 44.5mm x 9.4mm x 12.7mm. It features under-voltage lockout (UVLO) protection and operates over a temperature range of -40°C to 85°C. The PTV05020WAH is designed for board-mounted power solutions where space efficiency and thermal performance are critical.
| Qty | Low | High |
|---|---|---|
| 1+ | $38.82 | $38.82 |
| 5+ | $37.38 | $37.38 |
| 10+ | $36.83 | $36.83 |
| 25+ | $36.25 | $36.25 |
| 40+ | $35.40 | $35.40 |
| 120+ | $34.82 | $34.82 |
| 280+ | $34.07 | $34.07 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is adjustable from 0.8V to 3.6V.
The maximum output current is 18A.
The minimum input voltage is 4.5V.
The efficiency is up to 94%.
The operating temperature range is -40°C to 85°C.
It comes in a 12-SIP Module with through-hole mounting.
Yes, it is listed as RoHS3 Compliant.
