The PTV03020WAH is a non-isolated point-of-load (PoL) module from Texas Instruments designed for high-efficiency power conversion. It delivers up to 18A of output current with an adjustable output voltage range of 0.8V to 2.5V, making it suitable for powering low-voltage digital ICs.
Operating from a nominal 2.95V input, the module achieves a typical efficiency of 95%, reducing power dissipation in space-constrained applications. It includes under-voltage lockout (UVLO) protection for reliable startup and shutdown.
The module is housed in a 12-SIP (Single In-line Package) with through-hole mounting, measuring 44.5mm x 9.4mm x 12.7mm. It is rated for commercial ITE applications and operates over a temperature range of -40°C to 85°C.
| Qty | Low | High |
|---|---|---|
| 40+ | $32.34 | $32.34 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal input voltage is 2.95V.
The output voltage is adjustable from 0.8V to 2.5V.
The maximum output current is 18A.
The typical efficiency is 95%.
The operating temperature range is -40°C to 85°C.
The package is a 12-SIP through-hole module.
Yes, it is RoHS3 compliant (unverified).
