PTSA151235Z The Phoenix Contact PTSA151235Z is a green PCB terminal block designed for electrical connections. It features 12 positions and a 3.5 mm pitch.
Mfr Part #:

PTSA151235Z

Available from 1 distributors
Mfr Name: Phoenix Contact
Phoenix Contact
The Phoenix Contact PTSA151235Z is a green PCB terminal block designed for electrical connections. It features 12 positions and a 3.5 mm pitch.
✓ Total Stock: 250 pcs

PTSA151235Z Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Chanetech ✓
Non-Authorised Inventory information
250 pcs
On Request
250 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PTSA151235Z Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Arrangement
Color
Connection Method
Mounting Type
Number of Positions
Pitch
Rated Voltage
View Similar Products (0)

PTSA151235Z Description

Short technical summary and product information.

The Phoenix Contact PTSA151235Z is a PCB terminal block designed for reliable electrical connections. It offers 12 positions with a pitch of 3.5 mm, accommodating a nominal cross-section of 1.5 mm².



This terminal block is rated for a nominal current of 8 A and a voltage of 400 V (according to IEC/EN 60335-2-45). It utilizes a push-in spring connection method for secure wiring and is suitable for wave soldering processes. The component features a 45° conductor/PCB connection angle, a zigzag pin layout with offset soldering legs, and a solder pin length of 3.6 mm.



Configured in a two-row arrangement, the PTSA151235Z is green in color. Its design facilitates efficient PCB mounting and connection in various electronic applications.

PTSA151235Z Quick Information

Product Type: PCB Terminal Block
Series: PTSA151235Z
Canonical Name: Phoenix Contact PTSA151235Z PCB Terminal Block
Subcategory: Wire to Board Terminal Block

PTSA151235Z Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PTSA151235Z Features

  • 12 positions with 3.5 mm pitch.
  • Rated for 8A nominal current.
  • Rated for 400V nominal voltage.
  • Push-in spring connection method.
  • Suitable for wave soldering.

PTSA151235Z Applications

  • Enables push-in spring wiring for 1.5 mm² conductors.
  • Supports 8A current and 400V rated voltage.
  • Features 45° conductor angle for space-saving layouts.
  • Provides 12 positions in a two-row zigzag arrangement.

PTSA151235Z FAQs

7 frequently asked questions generated from this part’s specifications.
What is the nominal current rating for the Phoenix Contact PTSA151235Z?

The nominal current rating is 8 A.

What is the rated voltage of the PTSA151235Z terminal block?

The rated voltage is 400 V.

How many positions does the PTSA151235Z PCB terminal block have?

It has 12 positions.

What is the pitch of the PTSA151235Z terminal block?

The pitch is 3.5 mm.

What connection method does the PTSA151235Z use?

It uses a push-in spring connection method.

Is the PTSA151235Z suitable for wave soldering?

Yes, it is suitable for wave soldering.

What is the color of the PTSA151235Z terminal block?

The component is green.
