| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8,478 pcs
|
8478 pcs | On Request | 1 | On Request | On Request | 17+ | On Request | On Request | |
|
3,734 pcs
|
3734 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The PTN78060HAH from Texas Instruments is a non-isolated point-of-load (PoL) DC-DC converter module designed for commercial ITE applications. It provides a single regulated output with high efficiency.
Electrically, the module delivers a nominal 15V output at up to 3A with a typical efficiency of 96%. It includes under-voltage lockout (UVLO) protection for reliable operation.
The converter is housed in a compact 7-DIP through-hole package measuring 25.4mm x 15.7mm x 8.9mm. It operates over a temperature range of -40°C to 85°C and supports a wide commercial application scope.
The PTN78060HAH is RoHS3 compliant (unverified) and has an MSL rating of 1 (unlimited). It is suitable for board-mount power systems requiring a non-isolated, high-efficiency point-of-load converter.
| Qty | Low | High |
|---|---|---|
| 1+ | $40.10 | $40.10 |
| 5+ | $38.60 | $38.60 |
| 10+ | $38.01 | $38.01 |
| 25+ | $37.14 | $37.14 |
| 36+ | $36.39 | $36.39 |
| 108+ | $36.18 | $36.18 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal output voltage is 15V.
The maximum output current is 3A.
The typical efficiency is 96%.
The operating temperature range is -40°C to 85°C.
It comes in a 7-DIP through-hole module package.
Yes, it includes under-voltage lockout (UVLO) protection.
It is suitable for commercial ITE (Information Technology Equipment) applications.
