| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
244 pcs
|
244 pcs | On Request | 1 | On Request | On Request | 1209+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Memory Type | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package Quantity | |
| Pitch | |
| Quiescent Current | |
| Storage Temperature | |
| Tape & Reel | |
| Thickness | |
| Type | |
| Voltage | |
| Width |
The Texas Instruments PTH12060YAST is a 10A non-isolated DC DC converter module specifically designed for bus termination in DDR and QDR memory applications. It operates from an input voltage range of 10.8V to 13.2V and provides an adjustable output voltage from 0.55V to 1.8V.
Key electrical features include a maximum output current of 10A, with a typical quiescent current of 10mA. The module boasts efficiencies up to 91% and includes features such as On/Off Inhibit (for VTT Standby), Undervoltage Lockout (UVLO), and Output Overcurrent Protection (non-latching, auto-reset).
This module is designed for surface mount applications with dimensions of 25.3mm x 15.8mm x 9.0mm. It operates within a wide temperature range of -40°C to 85°C, making it suitable for various industrial environments. The PTH12060YAST is compatible with DDR, DDR2, and DDR3 memory types.
| Qty | Low | High |
|---|---|---|
| 1+ | $8.46 | $8.46 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The PTH12060YAST has a maximum output current of 10A.
The input voltage range for the PTH12060YAST is 10.8V to 13.2V.
The output voltage can be adjusted from 0.55V to 1.8V.
The operating temperature range is -40°C to 85°C.
The PTH12060YAST is in a 10-SMD Module package.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
