| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,014 pcs
|
3014 pcs | On Request | 1 | On Request | On Request | 20+ | On Request | On Request | |
|
1,669 pcs
|
1669 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,597 pcs
|
1597 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
216 pcs
|
216 pcs | On Request | 1 | On Request | On Request | 10+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage Range | |
| SVHC Present | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The Texas Instruments PTH12060WAH is a non-isolated point-of-load (PoL) DC-DC converter module designed for commercial ITE applications. It operates from a nominal 10.8V input and provides a regulated output adjustable from 1.2V to 5.5V at up to 10A. With a typical efficiency of 94%, this module minimizes power loss in space-constrained designs.
Housed in a 10-DIP through-hole package measuring 25.4mm x 15.7mm x 8.9mm, the PTH12060WAH is suitable for board-level power conversion where isolation is not required. Its wide operating temperature range of -40°C to 85°C allows use in industrial and commercial environments.
This module is ideal for powering FPGAs, ASICs, and other digital loads that require a low-voltage, high-current supply from a 10.8V bus. The adjustable output voltage provides design flexibility without external components.
| Qty | Low | High |
|---|---|---|
| 1+ | $28.89 | $28.89 |
| 5+ | $27.81 | $27.81 |
| 10+ | $26.73 | $26.73 |
| 25+ | $26.71 | $26.71 |
| 36+ | $26.11 | $26.11 |
| 108+ | $25.97 | $25.97 |
| 252+ | $25.94 | $25.94 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is adjustable from 1.2V to 5.5V.
The module can deliver up to 10A.
Typical efficiency is 94%.
The operating temperature range is -40°C to 85°C.
It is housed in a 10-DIP through-hole module.
The part is listed as RoHS3 Compliant (unverified).
