The Texas Instruments PTH04T220WAZ is a Non-Isolated Point-of-Load (PoL) DC-DC converter module designed for commercial ITE applications. It provides a single regulated output voltage adjustable from 0.69V to 3.6V with a rated output current of 16A. The module achieves a typical efficiency of 94%, making it suitable for power-sensitive designs.
This surface-mount module comes in an 11-SMD package measuring 25.4mm x 19.1mm x 9.1mm. It includes protection features such as overcurrent protection (OCP), overtemperature protection (OTP), and undervoltage lockout (UVLO), along with a remote on/off control function. The operating temperature range spans -40°C to 85°C, allowing use in a variety of environments.
The PTH04T220WAZ is RoHS3 compliant and has an MSL rating of 1 (unlimited floor life). It is intended for commercial ITE applications where a compact, high-efficiency power conversion solution is required.
| Qty | Low | High |
|---|---|---|
| 1+ | $27.44 | $27.44 |
| 5+ | $26.42 | $26.42 |
| 10+ | $25.99 | $25.99 |
| 25+ | $25.46 | $25.46 |
| 42+ | $23.73 | $23.73 |
| 252+ | $23.63 | $23.63 |
| 504+ | $22.46 | $22.46 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is adjustable from 0.69V to 3.6V.
The rated output current is 16A.
Typical efficiency is 94%.
The operating temperature range is -40°C to 85°C.
It comes in an 11-SMD Module package for surface mount.
Yes, it is RoHS3 compliant.
It includes overcurrent protection (OCP), overtemperature protection (OTP), and undervoltage lockout (UVLO).
