The Texas Instruments PTH03030WAS is a non-isolated Point-of-Load (PoL) DC DC converter designed for ITE commercial applications. This module provides a 30A output current with a nominal voltage of 2.95V and boasts a high efficiency of 93%.
Key features include remote On/Off control, Over-Current Protection (OCP), Over-Temperature Protection (OTP), and Under-Voltage Lockout (UVLO). The converter operates within a temperature range of -40°C to 85°C.
Packaged in a 13-SMD module, it is designed for surface mount installation. Its dimensions are 34.8mm in length, 28.5mm in width, and 9.6mm in height.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The PTH03030WAS provides a maximum output current of 30A.
The nominal output voltage for the PTH03030WAS is 2.95V.
The efficiency of the PTH03030WAS is 93%.
Key features include Remote On/Off, OCP, OTP, and UVLO.
The operating temperature range is -40°C to 85°C.
The PTH03030WAS is in a 13-SMD Module package.
The PTH03030WAS is designed for surface mount installation.
