| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
31,153 pcs
|
31153 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Halogen Free | |
| Industrial Grade | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation | |
| Storage Temperature | |
| Tape & Reel |
The Everlight Electronics PT333-3C is a high-speed, high-sensitivity NPN silicon epitaxial planar phototransistor. It is molded in a standard 5mm package with black epoxy, making it sensitive to infrared radiation.
Key electrical characteristics include a collector-emitter voltage of 30V, an emitter-collector voltage of 5V, and a maximum collector current of 20mA. The device operates within a temperature range of -25°C to +85°C. Its electro-optical properties include a peak sensitivity wavelength of 940nm and a spectral bandwidth ranging from 400nm to 1100nm.
This phototransistor is suitable for applications involving infrared systems, cameras, and printers. It features a fast response time of 15μS and a fall time of 15μS, with a collector dark current of 100nA maximum. The on-state collector current is typically between 2.67mA and 7.07mA under specific conditions.
The PT333-3C is Pb-free and Halogen-free, complying with RoHS and REACH standards. It is packaged in a standard 5mm through-hole component.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating temperature range for the PT333-3C is -25°C to +85°C.
The peak sensitivity wavelength of the PT333-3C is 940nm.
The collector-emitter breakdown voltage for the PT333-3C is 30V.
The maximum collector current for the PT333-3C is 20mA.
Yes, the PT333-3C is RoHS3 Compliant.
Yes, the PT333-3C is Halogen Free.
