| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6,000 pcs
|
6000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accuracy | |
| Cable Length | |
| Probe Length | |
| Storage Temperature | |
| Tape & Reel |
The HERAEUS PT1000 is a lead-type temperature sensor utilizing the resistance change of a platinum resistor with temperature. It is constructed with a 304 stainless steel probe, offering resistance to high temperatures and corrosion, and employs double pressure ring technology for enhanced waterproofing.
This sensor is suitable for measuring the temperature of solid, liquid, or gas media within a range of -50 to 300°C. The probe operates within -50 to 300°C, while the cable is rated for -50 to 200°C. It features a Class B+ accuracy of ±0.5°C typical and a fast thermal response.
The conductor uses special PTFE silver-plated shielded wire, providing a wide operating temperature range and stable anti-interference effects. With an IP68 rating, the PT1000 is well-suited for demanding environments. Its small size and lightweight design facilitate easy installation.
Commonly used in automated temperature measurement and control systems, the PT1000 finds applications in liquid detection, food monitoring, storage cold chains, industrial boilers, and aquacultures. The standard U-shaped terminal ensures a more stable connection.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.50 | $1.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The probe of the PT1000 sensor can operate in the range of -50 to 300°C.
The PT1000 sensor has a Class B+ accuracy, typically ±0.5°C.
The PT1000 sensor can measure the temperature of solid, liquid, or gas media.
The PT1000 sensor has an IP68 rating.
The cable length of the PT1000 sensor is 3 meters.
