The CUI Inc. PSK-S10C-9 is an enclosed AC/DC converter with a 9V output voltage and a maximum output current of 1.1A, delivering 10W of power. It operates with an efficiency of 80% and accepts a wide input voltage range of 85-264 VAC or 100-370 VDC.
This converter is suitable for applications such as household appliances and ITE (Commercial). It features universal input and is compliant with various standards including 55014-1, 55014-2, 55024, 55032 Class A, 60335-1, 60950-1, 61000-3-2, and 62368-1. The operating temperature range is -40°C to 70°C with derating.
With a compact size of 53.8mm x 28.8mm x 19.0mm, it is designed for through-hole mounting. The isolation voltage is rated at 4 kV. The PSK-S10C-9 is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1.
85~264 VAC, 100~370 VDC.
9V nominal output at up to 1.1A maximum current.
10W nominal.
4kV.
-40°C to 70°C with derating.
4-DIP Module with through-hole mounting.
53.8mm x 28.8mm x 19.0mm.
