The CUI Inc. PSK-S10C-24 is an enclosed AC/DC converter designed for various applications, including household appliances and ITE commercial use. It provides a stable 24V output with a maximum current of 450mA, delivering a total power of 11W.
This converter operates with a wide input voltage range of 85 to 264 VAC and 100 to 370 VDC, offering flexibility in power source selection. It boasts an efficiency of 83% and features universal input capabilities. The operating temperature range is -40°C to 70°C with derating.
Key electrical specifications include an isolation voltage of 4 kV. The unit is compliant with several standards, including 55014-1, 55014-2, 55024 Class A, 60335-1, 60950-1, 61000-3-2, and 62368-1. The physical dimensions are 53.8mm in length, 28.8mm in width, and 19.0mm in height.
The PSK-S10C-24 is mounted via through-hole and comes in a tray package. It is RoHS3 compliant and has an MSL rating of 1.
The input voltage range is 85-264 VAC or 100-370 VDC.
It provides 24V at 450mA, 11W.
The isolation voltage is 4 kV.
The operating temperature range is -40°C to 70°C with derating.
It comes in a 4-DIP Module with through-hole mounting.
The efficiency is 83%.
It complies with standards including 55014-1, 60335-1, 60950-1, 61000-3-2, and 62368-1.
