The CUI Inc. PSK-45-48-T is an enclosed AC-DC power supply from the PSK-45 series, delivering 45W of power with a nominal 48VDC output and a maximum current of 940mA. It operates with a universal input voltage range of 85-264 VAC or 100-370 VDC and boasts a typical efficiency of 87%.
Designed for reliability, this converter includes over-voltage, over-current, and short-circuit protections. It features a 4000 VAC isolation rating and meets IEC/EN/UL 62368 standards, making it suitable for ITE (Commercial) applications. The operating temperature range is -40°C to 70°C with derating.
With a compact chassis mount design, the PSK-45-48-T has dimensions of 135.0mm x 70.0mm x 37.9mm. It also meets CISPR32/EN 55032 Class B standards for EMI/EMC without external components.
The output voltage is 48 VDC and the maximum output power is 45 W.
The AC input range is 85-264 VAC and the DC input range is 100-370 VDC.
The operating temperature range is -40°C to 70°C with derating.
It includes over voltage protection (56 V clamp/hiccup), over current protection (110% auto recovery), and continuous short circuit protection with auto recovery.
The typical efficiency is 87%.
The dimensions are 135.0 mm (5.32") length, 70.0 mm (2.76") width, and 37.9 mm (1.49") height.
