The CUI Inc. PSK-45-15-T is an enclosed AC-DC power supply from the PSK-45 series, delivering 45W of power with a single 15V output. It is designed for ITE (Commercial) applications and offers a universal input voltage range of 85-264 VAC or 100-370 VDC.
Key electrical specifications include a maximum output current of 3A, a typical efficiency of 85%, and protections such as over-voltage, over-current, and short-circuit. The unit provides 4000 VAC isolation between input and output and operates within a temperature range of -40°C to 70°C with derating.
This power supply is chassis mountable and meets safety standards including IEC/EN/UL 62368-1. Its dimensions are 135.0mm x 70.0mm x 37.9mm. The PSK-45-15-T is certified by CE and cURus approval agencies.
The output voltage is 15 Vdc.
The maximum output current is 3 A.
The power rating is 45W.
The typical efficiency is 85%.
The input voltage range is 85-264 VAC or 100-370 VDC.
The operating temperature range is -40°C to 70°C with derating.
It uses chassis mounting.
