| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Frequency | |
| Height | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Output Power | |
| Output Voltage | |
| Package / Case | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Tape & Reel | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The CUI Inc. PSK-40D-15 is an enclosed AC-DC power supply designed for internal use. It delivers a 15VDC output with a maximum current of 2.67A, providing up to 40W of power.
This power supply accepts a wide universal input voltage range of 85-305VAC or 100-430VDC, making it suitable for global applications. It boasts a high efficiency of up to 90% at 230VAC input and operates within an ambient temperature range of -40°C to 85°C.
Key electrical specifications include ±2% output voltage accuracy, ±0.5% line regulation, and ±1% load regulation for the 15V model. It offers protections such as over-voltage, over-current, and short-circuit protection. The unit is designed for Through Hole mounting and comes in a 4-DIP Module package.
Compliance features include certification to 62368-1 standards with CE and UKCA approvals. It meets CISPR32/EN55032 Class B emissions standards and includes ESD, EFT/burst, and surge protection capabilities.
The PSK-40D-15 has a nominal output voltage of 15 VDC.
The maximum output current for the PSK-40D-15 is 2.67A.
The PSK-40D-15 accepts a universal input voltage range of 85-305 VAC or 100-430 VDC.
The operating ambient temperature range for the PSK-40D-15 is -40°C to 85°C.
The PSK-40D-15 has a typical efficiency of 90% at 230 Vac input.
The PSK-40D-15 is supplied in a 4-DIP Module package.
