| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Height | |
| Industrial Grade | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Package / Case | |
| Power | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The CUI Inc. PSK-15D-5 is a versatile AC/DC converter designed for various applications, including household appliances, ITE (Commercial), and medical equipment. This enclosed unit provides a stable 5Vdc output with a maximum current of 3A, totaling 15W of power.
Key electrical specifications include an input voltage range of 85-305 Vac and an efficiency of 85%. The operating temperature range is -40°C to 85°C, with derating applied at higher temperatures. The converter meets safety standards such as CE and cURus, and complies with standard numbers 60335-1, 60601-1, and 62368-1.
Mechanically, the PSK-15D-5 features a compact size with dimensions of 47.6mm in length, 26.8mm in width, and 23.5mm in height. It is designed for through-hole mounting and comes in a 5-DIP module package with 4 leads. Environmental compliance includes RoHS3 compliance, MSL 1 Unlimited, and REACH Unaffected status.
The CUI Inc. PSK-15D-5 has an output voltage of 5 Vdc.
The PSK-15D-5 accepts an input voltage range of 85-305 Vac.
The PSK-15D-5 can provide a maximum output current of 3A.
The CUI Inc. PSK-15D-5 has a power rating of 15W.
The operating temperature range for the PSK-15D-5 is -40°C to 85°C, with derating.
The PSK-15D-5 is designed for through-hole mounting.
The dimensions of the PSK-15D-5 are 47.6mm in length, 26.8mm in width, and 23.5mm in height.
