The CUI Inc. PSK-15D-3 is an enclosed AC/DC converter designed for various applications including household appliances, ITE (Commercial), and Medical. It provides a single output of 3.3V and can deliver up to 4A of current, with a total power rating of 13W.
This converter operates across a wide input voltage range of 85-305 VAC or 100-430 VDC, ensuring flexibility in power source selection. It boasts an efficiency of 82% and features 4 kV of isolation.
The PSK-15D-3 is designed for through-hole mounting and comes in a 5-DIP Module, 4 Leads package. Its operating temperature range is -40°C to 85°C with derating. The unit complies with safety standards such as 60335-1, 60601-1, and 62368-1, and is RoHS3 compliant.
The output voltage is 3.3V.
The maximum output current is 4A.
The power rating is 13W.
The input voltage range is 85-305 VAC or 100-430 VDC.
The efficiency is 82%.
The operating temperature range is -40°C to 85°C (with derating).
The dimensions are 47.6mm L x 26.8mm W x 23.5mm H.
