The CUI Inc. PSK-10D-9-T is an enclosed AC/DC power supply designed for internal use, delivering a stable 9V output at up to 1.1A, for a total of 10W.
This series boasts a wide AC input range of 85-305 Vac and operates efficiently with a typical efficiency of 81% at 230 Vac input. It is designed for a broad operating temperature range from -40°C to +85°C, with derating applied at higher temperatures.
Key electrical specifications include ±2% output voltage accuracy, ±0.5% line regulation, and ±1.0% load regulation. Protections include over-voltage, over-current, and short-circuit with auto-recovery features. The unit is certified to safety standards such as 62368-1, 61558, and 60335-1, and meets Class B emissions standards.
Designed for chassis mounting, the PSK-10D-9-T has dimensions of 76.0mm x 31.5mm x 29.8mm. Its robust design and comprehensive safety certifications make it suitable for applications in household appliances and ITE commercial equipment.
The output voltage is 9 Vdc.
The maximum output current is 1.1 A.
The power rating is 10W.
The typical efficiency is 81%.
The operating temperature range is -40°C to 85°C.
It is designed for chassis mounting.
It is certified to 62368-1, 61558, and 60335-1 standards.
