The Mean Well USA PSD-45C-12 is a 45W DC/DC converter designed for various applications. It provides a single 12VDC output at 3.75A, with a nominal input voltage of 48VDC and a wide input range of 36-72VDC.
This converter features an open frame construction and is designed for chassis mounting. It offers an efficiency of 83% and an isolation voltage of 500VDC. The operating temperature range is -10°C to 60°C, with derating applicable.
Key specifications include a total power of 45W, a 2:1 input voltage range, and compliance with CB and CE safety standards. The dimensions are 5.00" L x 2.99" W x 1.18" H (127.0mm x 76.0mm x 30.0mm).
The PSD-45C-12 is suitable for ITE (Commercial) applications and is RoHS3 compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is from 36VDC to 72VDC.
The output voltage is 12VDC.
The maximum output current is 3.75A.
The typical efficiency is 83%.
It operates between -10°C and 60°C.
It is RoHS3 compliant.
