The Mean Well PSD-30A-5 is a versatile DC/DC converter designed for various applications. It features an open-frame construction and chassis mount type, making it suitable for integration into custom power solutions.
This converter operates with an input voltage range of 9.2 to 18Vdc and provides a stable 5Vdc output at a maximum current of 5A, resulting in a total power output of 25W. Its efficiency is rated at 77%.
The operating temperature range for the PSD-30A-5 is from -20°C to 60°C, with derating applied at higher temperatures. It offers an isolation voltage of 1.5 kV and is designed for ITE (Commercial) applications. The unit has a single output.
Key dimensions include a length of 101.6mm (4.00"), a width of 50.8mm (2.00"), and a height of 30.0mm (1.18").
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 5Vdc.
The maximum output current is 5 Amps.
The power rating is 25 Watts.
The input voltage range is 9.2 to 18Vdc.
The operating temperature range is -20°C to 60°C, with derating.
It uses chassis mount.
