The Bel Power Solutions PSC246-9LIR is a positive switching regulator designed for electronic systems requiring DC-DC power conversion without input-to-output isolation. It offers high efficiency up to 97% and a maximum output power of 144W.
Key electrical specifications include a 24VDC output voltage and a 6A output current, derived from an input voltage range of 31VDC to 144VDC. The converter operates efficiently, with a typical efficiency of 94% and a maximum of 97%.
Designed for robust operation, the PSC246-9LIR has an operating temperature range of -40°C to 71°C. Its mechanical dimensions are 151.0mm x 32.2mm x 88.0mm (5.94" x 1.27" x 3.46"). It supports chassis mounting and features conformal coating for enhanced durability.
This DC-DC converter is suitable for ITE (Commercial) and Railway applications. It includes features such as input undervoltage lockout, output voltage adjustment, and an inhibit function, making it versatile for various system designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The PSC246-9LIR has an output voltage of 24VDC.
The input voltage range for the PSC246-9LIR is 31VDC to 144VDC.
The PSC246-9LIR has a maximum power output of 144W.
The operating temperature range is -40°C to 71°C.
The PSC246-9LIR supports both Chassis Mount and Rack Mount.
The PSC246-9LIR is RoHS3 Compliant.
