| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
41 pcs
|
41 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Current | |
| Dimming | |
| Efficiency | |
| Height | |
| Industrial Grade | |
| Ingress Protection | |
| Lead Style | |
| Length | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Ratings | |
| Tape & Reel | |
| Termination Style | |
| Topology | |
| Type | |
| Voltage | |
| Width |
The PSB30E-0700-34-T is a 24W constant current LED driver from ERP Power, designed for indoor commercial and residential lighting applications. It operates from a universal input voltage range of 120 to 277 VAC and delivers a constant 700 mA output at 34V.
Key electrical characteristics include a typical efficiency of 90%, power factor greater than 0.9, and total harmonic distortion below 20%. The driver supports Tri-Mode dimming (TRIAC, ELV, and 0-10V analog) with a dimming range from 1% to 100%, and includes a dim-to-off feature.
The driver meets multiple compliance standards including CB, CE, cULus, FCC, and complies with ENERGY STAR, DLC, CA Title 24, NEMA SSL-1, and IEEE 1789 flicker recommendations. Surge protection meets IEC61000-4-5 and ANSI/IEEE C62.41 categories.
Mechanically, it features an IP20-rated case with terminal block connections. Dimensions are 154.2 x 26.2 x 21.85 mm (6.07 x 1.03 x 0.86 in). Maximum case hot spot temperature is 90°C, with a typical lifetime of 50,000 hours at Tc ≤ 75°C.
| Qty | Low | High |
|---|---|---|
| 41+ | $29.25 | $29.25 |
| 100+ | $29.26 | $29.26 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 120 to 277 VAC.
Yes, the part is listed as RoHS3 compliant, though this data is low confidence and not verified from the datasheet.
The nominal output current is 700 mA, programmable from 50% to 100%.
It supports analog (0-10V), ELV, and TRIAC dimming with a dimming range of 1% to 100%.
Typical efficiency is 90%.
Lifetime is 50,000 hours at Tc ≤ 75°C typical.
The case is rated IP20.
