| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Length | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| SVHC Present | |
| Voltage | |
| Width |
The Phihong USA PSA60R-120-R is an AC/DC wall mount adapter designed for ITE commercial applications. It delivers a stable 12V output with a maximum current of 5A, providing a total power of 60W. This adapter meets Level V efficiency standards and is suitable for international use.
Featuring a compact wall mount form factor (Class II), the PSA60R-120-R includes a multi-blade input connector and a standard barrel plug output connector (2.1mm I.D. x 5.5mm O.D. x 10.0mm) with a positive center polarization. The operating temperature range is from 0°C to 40°C. The unit has a low no-load power consumption of 300mW (Max) and a cord length of 49.21 inches (1.25m).
Installation requires verifying output compatibility with the equipment. Ensure good ventilation during use, maintaining a clearance from heat sources. The adapter should be placed on a reliable surface and kept away from damp environments or water. Output current and wattage must not exceed rated values.
12V DC.
0°C to 40°C.
Level V.
CE and cULus.
Barrel plug, 2.1mm I.D. x 5.5mm O.D. x 10.0mm.
Multi-Blade (sold separately).
Positive center.
