| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6,898 pcs
|
6898 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Common Mode Transient Immunity (Min) | |
| Current | |
| Data Rate | |
| Input Type | |
| Inputs | |
| Lead Spacing | |
| Mounting Type | |
| Number of Channels | |
| Operating Temperature | |
| Output Type | |
| Propagation Delay | |
| Propagation Delay tpLH | |
| Supplier Device Package | |
| Tape & Reel | |
| Voltage | |
| Voltage Supply |
The H11L1SR2VM from onsemi is a logic output optoisolator designed for signal isolation in electronic circuits. It provides a high isolation voltage of 4170Vrms and features an open collector output type.
Key electrical specifications include a supply voltage range of 3V to 15V, a typical forward voltage of 1.2V, and a maximum DC forward current of 30mA. The device supports a data rate of 1MHz and an output current of 50mA per channel. It has a single channel configuration.
This optocoupler is housed in a 6-SMD, Gull Wing package suitable for surface mounting. The operating temperature range is -40°C to 85°C. The part is compliant with RoHS and REACH standards, with an MSL rating of 1.
Applications for this component include general-purpose signal isolation where high voltage breakdown is required. Its surface mount package facilitates integration into compact PCB designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.43 | $1.43 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The H11L1SR2VM provides 4170Vrms of isolation.
The H11L1SR2VM features an open collector output type.
The H11L1SR2VM supports a data rate of 1MHz.
The H11L1SR2VM operates between -40°C and 85°C.
The H11L1SR2VM is supplied in a 6-SMD, Gull Wing package for surface mounting.
