PRT-14017 This is a 2x20 tall male header with 0.1in pitch for extending Raspberry Pi GPIO heights. It is through-hole mount and suitable for use with enclosures.
Mfr Part #:

PRT-14017

Available from 1 distributors
Mfr Name: SparkFun Electronics
SparkFun Electronics
This is a 2x20 tall male header with 0.1in pitch for extending Raspberry Pi GPIO heights. It is through-hole mount and suitable for use with enclosures.
✓ Total Stock: 1 pcs
$ Price Range: $3.50

PRT-14017 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Emiteli ✓
Non-Authorised Inventory information
1 pcs
On Request
1 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PRT-14017 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Accessory Type
For Use With
Gender
Lead Spacing
Lead Style
Mounting Type
Number of Positions
Pitch
View Similar Products (0)

PRT-14017 Description

Short technical summary and product information.

The PRT-14017 is a 40-position (2x20) male pin header designed for use with Raspberry Pi single-board computers. It features a 0.1 inch pitch and through-hole mounting, making it easy to solder onto a prototyping board or shield. This tall header provides additional height to accommodate enclosures or other components that may sit above the Raspberry Pi board. The header is male gender and is commonly used to connect GPIO pins to external circuits. It is RoHS3 compliant and has an MSL of 1 (unlimited). The part is manufactured by SparkFun Electronics and is available in single-piece packaging.

PRT-14017 Quick Information

Product Type: Connector
Canonical Name: Raspberry Pi GPIO Tall Header 2x20 Male Pin Header
Subcategory: Pin Headers

PRT-14017 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PRT-14017 Estimated Pricing

Qty Low High
1+ $3.50 $3.50

Estimated market price range - modelled values for guidance only, not live distributor offers.

PRT-14017 Features

  • 40-position 2x20 male pin header.
  • 0.1 inch pitch for standard breadboard compatibility.
  • Through-hole mounting for secure soldering.
  • Designed for Raspberry Pi GPIO extension.
  • Tall profile accommodates enclosures.

PRT-14017 Applications

  • Extend GPIO pins on Raspberry Pi boards.
  • Connect to prototyping shields and HATs.
  • Use in projects requiring enclosure clearance.

PRT-14017 FAQs

5 frequently asked questions generated from this part’s specifications.
How many positions does the PRT-14017 header have?

40 positions in a 2x20 configuration.

What is the pitch of this GPIO header?

0.1 inches.

What mounting type does this header use?

Through hole.

What is the gender of this connector?

Male.

What is this header designed for use with?

Raspberry Pi.
