| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Features | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Length | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Power (Watts) | |
| Region Utilized | |
| Standard Number | |
| Voltage | |
| Width |
The GlobTek, Inc. PR9SA8000A00-IMR6B is a versatile AC/DC Desktop Adapter designed for ITE (Commercial) and Medical applications. It provides a stable 5V output with a maximum current of 8A, delivering a total power of 40W.
This adapter meets high efficiency standards, achieving Level VI and CoC Tier 2 compliance. It operates within a temperature range of -20°C to 40°C and features a ruggedized, IP68-rated enclosure for dust-tight and waterproof protection. The input connector is wire leads, and the output connector is also stripped, tinned wire leads, with a cord length of 23.6 inches (0.60m).
Key specifications include a no-load power consumption of 75mW maximum. The adapter is designed in a Desktop (Class II) form factor and is suitable for international use. It adheres to several safety standards, including 60601-1-11, 60601-1-2, 60950-1, and 62368-1, and has received numerous agency approvals such as CB, CE, cETLus, and PSE.
The output voltage is 5V.
The maximum output current is 8A.
The power rating is 40W.
The operating temperature range is -20°C to 40°C.
The dimensions are 114.8mm x 57.1mm x 39.0mm.
It complies with 60601-1-11, 60601-1-2, 60950-1, and 62368-1 standards.
