PR2C10DC12K The Hasco Relays PR2C10DC12K is a DPDT power relay designed for through-hole mounting. It features a 10A contact rating and a 12VDC coil voltage.
Mfr Part #:

PR2C10DC12K

Available from 1 distributors
Mfr Name: Hasco Relays
Hasco Relays
The Hasco Relays PR2C10DC12K is a DPDT power relay designed for through-hole mounting. It features a 10A contact rating and a 12VDC coil voltage.
✓ Total Stock: 20 pcs
$ Price Range: $2.00

PR2C10DC12K Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
DYNACO PRODUCTS ✓
Non-Authorised Inventory information
20 pcs
On Request
20 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PR2C10DC12K Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Coil Current
Coil Insulation
Coil Type
Coil Voltage
Contact Form
Contact Material
Contact Rating (Current)
Insulation Resistance
Mounting Type
Must Operate Voltage
Must Release Voltage
Operate Time
Operating Temperature
Release Time
Storage Temperature
Switching Voltage
Tape & Reel
Termination Style
View Similar Products (0)

PR2C10DC12K Description

Short technical summary and product information.

The PR2C10DC12K from Hasco Relays is a DPDT (2 Form C) power relay suitable for various electronic control applications. It is designed for through-hole mounting and utilizes a Silver Alloy contact material.



This relay operates with a 12VDC coil voltage and has a coil current of 44 mA. Key electrical specifications include a contact rating of 10A and a maximum switching voltage of 277VAC. The relay features a non-latching coil type, with a must-operate voltage of 9.6 VDC and a must-release voltage of 1.2 VDC. It offers an operate time of 15 ms and a release time of 5 ms.



The PR2C10DC12K is built with a Class B insulation system and can operate within an ambient temperature range of -40°C to 85°C. Its construction includes features like high breakdown voltage (5000VAC between coil and contacts) and a unit weight of approximately 18g.



Typical applications for this power relay include general electronic controls, machine tool controls, energy control circuits, industrial machinery controls, and consumer electronics such as air conditioners and refrigerators.

PR2C10DC12K Quick Information

Product Type: Power Relay
Series: PR
Canonical Name: PR2C10DC12K DPDT Power Relay
Subcategory: Power Relay

PR2C10DC12K Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PR2C10DC12K Estimated Pricing

Qty Low High
1+ $2.00 $2.00

Estimated market price range - modelled values for guidance only, not live distributor offers.

PR2C10DC12K Features

  • DPDT (2 Form C) contact arrangement.
  • 10A contact rating at 277VAC.
  • 12VDC non-latching coil voltage.
  • Operates from -40°C to 85°C.
  • Through-hole mounting termination style.

PR2C10DC12K Applications

  • Suitable for general electronic controls.
  • Used in machine tool control systems.
  • Applicable for energy control circuits.
  • Designed for industrial machinery controls.
  • Can be used in consumer electronics.

PR2C10DC12K FAQs

6 frequently asked questions generated from this part’s specifications.
What is the contact arrangement of the relay?

The relay has a DPDT (Double Pole Double Throw) contact arrangement.

What is the coil voltage of the relay?

The coil voltage is 12 VDC.

What is the maximum switching voltage?

The maximum switching voltage is 277 VAC.

What is the contact rating of the relay?

The contact rating is 10 A.

What mounting style does the relay use?

The relay uses through-hole mounting style.

Is the relay RoHS compliant?

Yes, it is RoHS3 compliant.
