| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Output Voltage | |
| Power (Watts) | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Width |
The Tripp Lite PR15 is a linear AC-to-DC power supply designed for reliable and precise power conversion. It outputs 13.8VDC with a continuous current rating of 15A, delivering up to 207W of power. This unit is ideal for applications requiring stable DC power, such as ham radios, test bench equipment, and commercial/land-mobile radios.
Featuring solid-state integrated circuitry, the PR15 maintains excellent voltage regulation within ±0.5V, ensuring consistent performance across varying loads. High-quality filtering provides very low ripple and noise (0.05V maximum), making it suitable for sensitive electronic equipment. The power supply includes crowbar overvoltage protection and current-limiting electronic foldback for safeguarding connected devices.
Designed with a compact and low-profile footprint, the PR15 maximizes operating space. It operates from a standard 120VAC input and features a heavy-duty power transformer for complete isolation from AC line noise. Large heat sinks and a vented cabinet ensure cool operation for continuous use and extended component life. Connectors are hardwire terminals for positive and negative DC outputs.
The input voltage is 120VAC.
The output is 13.8VDC at 15A continuous.
The operating temperature range is 0°C to 40°C.
Ripple and noise is 0.05V maximum.
Output regulation is ±0.5V.
The unit weighs 5.90kg (13 lbs).
