PQAE50-D48-S5-U The CUI Inc. PQAE50-D48-S5-U is a 50W isolated DC-DC converter with a 36-75 VDC input range and a 5V/10A output. It offers 1500 Vdc isolation and a wide operating temperature range.
Mfr Part #:

PQAE50-D48-S5-U

Mfr Name: CUI Inc.
CUI Inc.
The CUI Inc. PQAE50-D48-S5-U is a 50W isolated DC-DC converter with a 36-75 VDC input range and a 5V/10A output. It offers 1500 Vdc isolation and a wide operating temperature range.
Stock on Request
$ Price Range: $0.99

PQAE50-D48-S5-U Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Approval Agency
Current
Efficiency
Filter Type
Height
Lead Spacing
Length
Mounting Type
Number of Outputs
Operating Temperature
Output Current
Output Power
Output Voltage
Power (Watts)
Tape & Reel
Type
Voltage
Width

PQAE50-D48-S5-U Description

Short technical summary and product information.

The CUI Inc. PQAE50-D48-S5-U is an isolated DC-DC converter from the PQAE50 series, designed for reliable power conversion in various applications. It features a 2:1 input voltage range of 36-75 Vdc and provides a single, regulated output of 5V at up to 10A, delivering a total of 50W of power.



Key electrical specifications include 1500 Vdc isolation, ensuring safety and signal integrity. The converter operates efficiently with up to 91% typical efficiency and offers protection against short circuit, over current, and over voltage conditions. It also includes input under-voltage protection and remote on/off control.



Designed for demanding environments, this DC-DC converter boasts a wide operating temperature range of -40°C to 105°C. Its chassis mount package facilitates integration into systems. The PQAE50-D48-S5-U is EN/BS EN 62368 certified, making it suitable for ITE (Commercial) applications.

PQAE50-D48-S5-U Quick Information

Product Type: DC DC Converter
Series: PQAE50
Canonical Name: CUI Inc. PQAE50-D48-S5-U DC-DC Converter
Subcategory: Isolated Module

PQAE50-D48-S5-U Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PQAE50-D48-S5-U Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

PQAE50-D48-S5-U Features

  • Up to 50 W isolated output power.
  • Wide 36-75 Vdc input voltage range.
  • Single regulated 5V output at 10A.
  • 1,500 Vdc isolation rating.
  • Wide -40°C to 105°C operating temperature.

PQAE50-D48-S5-U Applications

  • Suitable for ITE (Commercial) applications.
  • Provides isolated power conversion.
  • Designed for wide input voltage ranges.
  • Offers robust protection features.

PQAE50-D48-S5-U FAQs

7 frequently asked questions generated from this part’s specifications.
What is the input voltage range of the PQAE50-D48-S5-U?

The input voltage range is 36 to 75 VDC.

What is the output voltage of this converter?

The output voltage is 5 Vdc.

What is the maximum output current?

The maximum output current is 10A.

What is the efficiency of the PQAE50-D48-S5-U?

The typical efficiency is 91%.

What is the maximum ripple and noise level?

The maximum ripple and noise is 200 mVp-p.

What is the operating temperature range?

The operating temperature range is -40°C to 105°C.

Is this product RoHS compliant?

RoHS3 compliance status is unverified.
