The CUI Inc. PQAE50-D48-S12-T is an enclosed DC-DC converter from the PQAE50 series, designed for ITE (Commercial) applications. It provides a single, regulated 12V output with a maximum current of 4.167A and a total output power of 50W.
Key electrical features include a 2:1 input voltage range (36-75 Vdc for 48V models), 1,500 Vdc isolation, and up to 92% efficiency. The converter includes protection against short circuit, over current, over voltage, and input under voltage conditions. It also features remote on/off control.
This converter operates within a wide temperature range of -40°C to 105°C, with derating. It is chassis mounted and has dimensions of 76.0mm x 31.5mm x 21.2mm. The unit is certified to EN/BS EN 62368-1 standards.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 12 Vdc.
The maximum output current is 4.167 A.
The maximum power output is 50W.
The typical efficiency is 92%.
The operating temperature range is -40°C to 105°C.
The isolation voltage is 1,500 Vdc.
It is a chassis mount type.
