| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Average Efficiency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Insulation Resistance | |
| Length | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Output Power | |
| Power (Watts) | |
| Region Utilized | |
| Voltage | |
| Weight | |
| Width |
The Phihong USA PPL300U-120 is a 300W series desktop AC/DC adapter designed for various applications including networking, peripherals, and consumer electronics. It provides a stable 12.0V DC output at a maximum current of 24.0A, delivering up to 288.0W of power.
This adapter operates with a wide AC input voltage range of 90 to 264VAC and a frequency of 47 to 63Hz. It meets DOE Level VI efficiency standards, with an average efficiency of ≥ 87.5% at 115VAC input and a low no-load power consumption of ≤ 0.5W. Protection features include over-voltage, short circuit, and over-current protection, all with latching mechanisms.
The unit is housed in a non-vented, spill-proof case and features Class B EMI compliance. Its mechanical dimensions are 254mm x 116mm x 47mm, and it includes an IEC 60320 C14 input connector and a 6-position Molex output connector. The operating temperature range is from 0°C to +40°C.
The PPL300U-120 adapter provides a DC output voltage of 12.0V.
The maximum output current for the PPL300U-120 is 24.0A.
The PPL300U-120 adapter has an output power rating of 288.0W.
The PPL300U-120 adapter accepts an AC input voltage range of 90 to 264VAC.
The PPL300U-120 operates within a temperature range of 0°C to +40°C.
Yes, the PPL300U-120 is DOE Level VI Efficiency Compliant and has an average efficiency of ≥ 87.5% at 115VAC.
