The Delta Electronics PMT-24V50W1AA is an enclosed AC/DC power supply designed for ITE (Commercial) applications. It provides a single 24VDC output with a maximum current of 2.09A, delivering a total output power of 50W.
This converter operates with a wide input voltage range of 85 to 264 VAC and a frequency range of 47 to 63 Hz, ensuring compatibility in various regions. It boasts an efficiency of 86% and features adjustable output with universal input capabilities. The operating temperature range is -10°C to 70°C with derating.
Mechanically, the unit is enclosed and designed for chassis mounting. Its dimensions are 98.0mm x 98.0mm x 38.0mm, with a weight of 240g. The isolation voltage is rated at 3 kVAC. Approval agencies include CB, CCC, CE, cURus, and TUVgs, indicating broad compliance for industrial use.
The PMT-24V50W1AA provides a fixed 24 VDC output voltage.
The unit uses an enclosed chassis mount packaging style.
The converter operates reliably between -10°C and 70°C with derating.
The power supply delivers a maximum output power of 50 watts.
The device accepts an input voltage range of 85 to 264 VAC.
The unit features a 3 kVAC isolation voltage rating.
The converter achieves a typical efficiency rating of 86 percent.
