| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
This Delta Electronics PML-12V100W1AG is an AC/DC converter designed for ITE (Commercial) applications. It delivers 100W of power with a single 12V output and a maximum current of 8.5A. The converter operates with 86% efficiency and features an adjustable output.
Designed as an open frame unit, it is intended for chassis mounting. The operating temperature range is -10°C to 70°C with derating. It has an isolation voltage of 3 kV and is approved by CB, CE, CCC, cURus, and TUV.
Dimensions are 158.0mm in length, 97.0mm in width, and 38.0mm in height. The RoHS status is compliant with RoHS3, and the Moisture Sensitivity Level is 1 (unlimited).
The PML-12V100W1AG provides a single 12V output at 8.5A.
The PML-12V100W1AG operates at 86% efficiency.
The PML-12V100W1AG operates over -10°C to 70°C with derating.
The PML-12V100W1AG is chassis mountable.
The PML-12V100W1AG is rated for 100W output.
The PML-12V100W1AG is approved by CB, CE, CCC, cURus, and TUV.
