| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
17 pcs
|
17 pcs | On Request | 1 | On Request | On Request | On Request | On Request | 2026-02-23 21:33:16 |
| Category | |
| Manufacturer Name | |
| Current Rating (Max) | |
| DC Resistance (DCR) (Max) | |
| Filter Type | |
| Height | |
| Height (Max) | |
| Inductance @ Frequency | |
| Insulation Resistance | |
| Isolation | |
| Lead Spacing | |
| Length | |
| Mounting Type | |
| Number of Lines | |
| Operating Temperature | |
| Rated Voltage | |
| Tape & Reel | |
| Voltage Rating | |
| Width |
The PMCE-0330 from Premier Magnetics is a common mode line filter designed for medium and high power applications. It operates with a rated voltage of 250Vac and features a low profile construction.
Key electrical specifications include a maximum current rating of 1A and an inductance of 33 mH at 1 kHz. The DC resistance (DCR) is a maximum of 550mΩ. The filter provides 3750Vrms isolation and operates within a temperature range of -40°C to +80°C, with an insulation resistance greater than 100MΩ at 500Vdc.
Mechanically, the PMCE-0330 has a length of 21.00mm (0.826"), a width of 19.05mm (0.750"), and a maximum height of 27.00mm (1.063"). It is designed for Through Hole mounting.
This filter is suitable for power line filtering applications, helping to reduce electromagnetic interference (EMI) and radio frequency interference (RFI).
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The rated voltage is 250Vac.
The maximum current rating is 1A.
The inductance is 33 mH at 1 kHz.
The operating temperature range is -40°C to +80°C.
It is mounted using the Through Hole method.
