| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| SVHC Present | |
| Type | |
| Voltage | |
| Width |
This Delta Electronics PMB-24V50W1AA is an enclosed AC/DC converter designed for ITE (Commercial) applications. It delivers a power output of 50W with a DC output voltage of 24V at 2.1A. The converter features adjustable output and universal input capabilities, making it versatile for various power supply needs.
With a chassis mount type, this unit is suitable for integration into systems requiring a stable power source. It operates within a temperature range of -10°C to 70°C with derating. The dimensions are 98.0mm in length, 98.0mm in width, and 38.0mm in height. The unit boasts an efficiency of 86% and provides 3 kV of isolation voltage. It is approved by CB, CCC, CE, cURus, and TUV agencies.
The power output is 50W.
The DC output is 24V at 2.1A.
It uses chassis mount.
The operating temperature is -10°C to 70°C (With Derating).
The dimensions are 98.0mm x 98.0mm x 38.0mm.
It is approved by CB, CCC, CE, cURus, and TUV.
