| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Length | |
| Medical Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The FSP Technology Inc. PM202-12BN1 is an open frame AC/DC converter designed for chassis mounting. It provides a power output of 150W with a current rating of 12.5A and an output voltage of 12V.
This converter operates with an input voltage range of 90 to 264 VAC and boasts an efficiency of 91%. Key features include adjustable output and universal input capabilities, making it suitable for ITE (Commercial) and Medical applications. The operating temperature range is 0°C to 70°C with derating.
With dimensions of 127.0mm x 76.2mm x 38.1mm, the PM202-12BN1 is compliant with standards such as 60601-1 and 62368-1. It is RoHS3 compliant and has an MSL rating of 1.
The PM202-12BN1 has a power output of 150W.
The input voltage range is 90 to 264 VAC.
The current rating is 12.5 A.
The operating temperature range is 0°C to 70°C, with derating.
It complies with standards 60601-1 and 62368-1.
Yes, it is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
