The PM-DB27408 from Holt Integrated Circuits Inc. is a MIL-STD-1553 Data Bus IC designed for use with direct coupled or transformer coupled MIL-STD-1553 applications. It offers multiple ratio options compatible with various transceivers.
Key electrical specifications include a wide operating temperature range of -55°C to +130°C, Common Mode Rejection (CMR) greater than 45dB, and a maximum pulse width of 2 microseconds. The device also features a droop of less than 20% and overshoot/ringing of ±1V maximum.
This component is compliant with MIL-STD-1553A/B standards. It is packaged in a through-hole configuration and has a Moisture Sensitivity Level (MSL) of 3. The product longevity is indicated as greater than 10 years.
Applications for the PM-DB27408 include MIL-STD-1553 Interfaces, Smart Munitions, Stores Management, Sensor Interfaces, and Instrumentation.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.16 | $2.16 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating temperature range for the PM-DB27408 is -55°C to +130°C.
The Common Mode Rejection (CMR) is greater than 45dB.
The Moisture Sensitivity Level (MSL) is 3.
The PM-DB27408 is supplied in a through-hole package.
