The Cosel PLA50F-12 is an enclosed AC/DC power supply designed for ITE (Commercial) applications. It delivers a 12V output with a maximum current of 4.3A, providing up to 50W of power.
This converter features a universal input voltage range of 85 to 264 VAC and an efficiency of 82%. It is designed for chassis mounting and operates within a wide temperature range of -20°C to 70°C, with derating required at the temperature extremes. The unit complies with various safety and EMI standards, including CE, cURus, TUV, and FCC-B.
Key features include harmonic attenuation compliant with IEC61000-3-2 class A, low power consumption at no load, and a 5-year warranty. The PLA50F-12 is suitable for applications requiring a reliable and versatile enclosed power supply.
The input voltage range is 85 to 264 VAC.
The output is 12V at 4.3A, providing 50W.
The operating temperature range is -20°C to 70°C with derating.
It is approved to UL60950-1, C-UL (CSA60950-1), EN62368-1, and UL508 (PLA15F-150F).
Typical efficiency is 82%.
Cosel offers a 5-year warranty.
Yes, it complies with IEC61000-3-2 class A.
