| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Input Frequency | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Type | |
| Voltage |
The Cosel PLA15F-12 is an enclosed AC/DC power supply designed for reliable operation. It offers a 12V output voltage and a maximum output current of 1.3A, delivering up to 15.6W of power.
This converter features a universal input voltage range of 85-264 VAC, making it suitable for global applications. It operates within a wide temperature range of -20°C to +70°C, with derating required at the extremes. The unit complies with various safety and EMI standards, including UL60950-1, EN62368-1, FCC-B, and CISPR22-B.
Designed for chassis mounting, the PLA15F-12 is suitable for integration into various systems. Its low power consumption at no load and compliance with harmonic attenuator standards (IEC61000-3-2 class A) contribute to its efficiency and performance.
The output voltage is 12V.
The maximum output current is 1.3A.
The output wattage is 15.6W.
The input voltage range is 85 to 264 VAC.
The operating temperature range is -20°C to +70°C, with derating required.
Yes, it is RoHS3 Compliant.
