| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Input Frequency | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| SVHC Present | |
| Type | |
| Voltage |
The Cosel PLA150F-15 is an enclosed AC-DC converter designed for industrial applications. It delivers a stable 15V output voltage and a maximum power of 150W, with a rated output current of 10A.
This unit supports a wide universal input voltage range from 85 to 264 VAC, making it suitable for global use. It boasts an efficiency of up to 80.0% at 230V input. The converter complies with various safety and EMI standards, including CE, cURus, TUV, FCC-B, and CISPR22-B.
Designed for easy integration, the PLA150F-15 features a chassis mount type. It operates within a temperature range of -20°C to 70°C with derating. The series also offers features like harmonic attenuation compliant with IEC61000-3-2 class A and SEMI F-47 compliance as an option.
85-264 VAC.
15V at 10A (150W).
80% typical at 230VAC, 79% at 115VAC.
UL60950-1, C-UL (CSA60950-1), EN62368-1, UL508.
Chassis mount, enclosed type.
150mVp-p max at 0-50°C, 180mVp-p at -10-0°C.
Yes, complies with IEC61000-3-2 class A.
