The Cosel PLA100F-15 is an enclosed AC/DC power supply designed for chassis mounting. It offers a single output of 15V with a maximum current of 6.7A, delivering a total wattage of up to 100.5W under universal input conditions (AC85-264V).
This power supply operates within a wide temperature range of -20°C to 70°C and complies with various safety and EMI standards, including CE, cURus, TUV, and FCC-B. It features harmonic attenuation compliant with IEC61000-3-2 class A and offers SEMI F-47 compliance as an option.
Key electrical specifications include a typical efficiency of 79.5% at ACIN 230V, line regulation of 60mV maximum, and load regulation of 120mV maximum. The dimensions are 109.0mm in length, 40.9mm in width, and 97.0mm in height.
The output voltage is 15V.
The maximum output current is 6.7A.
The input voltage range is AC85 - 264V.
The operating temperature range is -20°C to 70°C.
It uses chassis mount.
