| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
64 pcs
|
64 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Center Tap | |
| Current | |
| Height | |
| Mounting Type | |
| Power | |
| Primary Winding(s) | |
| Secondary Winding(s) | |
| Storage Temperature | |
| Tape & Reel | |
| Termination Style | |
| Type | |
| Voltage |
The Tamura PL10-24-130B is a laminated power transformer with a power rating of 10VA. It is designed with dual primary and dual secondary windings, providing versatile output options. When connected in parallel, the secondary windings offer 12V at 840mA, while in series configuration, they provide 24V at 420mA. This transformer features a through-hole mounting type and PC pin termination style, making it suitable for various PCB applications.
With a core type of laminated construction, this transformer ensures reliable power conversion. It has a height of 36.20mm and dimensions of 47.60mm L x 39.70mm W. The unit is designed for international use with 115V/230V dual primary power capabilities and a Class B thermal rating (130°C). It also boasts a 3500Vrms HiPot rating between primary and secondary windings.
This component is suitable for applications requiring stable power transformation. Its robust construction and electrical specifications make it a reliable choice for power supply designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.00 | $3.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The power rating is 10VA.
The transformer has 12V in parallel and 24V in series configurations.
It uses through hole mounting with PC pins.
The insulation voltage is 3500Vrms.
It has a thermal class B rating (130°C).
Yes, it is RoHS3 compliant, although this status is unverified.
